CIE-2604C Pinza amperimétrica digital AC 1000A true RMS «CIE»
CARACTERÍSTICAS:
(±Peak hold)(TRUE RMS) (Temperature)(Backlight)
- 6600 counts, bar graph display
- Dual display of frequency with Current or
- Voltage or% Duty Cycle
- Auto ranging
- Auto power off
- Overload protections
- Safety input jacks
- Safety test leads
- Safety: EN61010-1, EN61010-2-032, CAT IV 600V, CATIII 1000V, CE approved
| Especificaciones | |
|---|---|
| Corriente CA | 66A, 660A, 1000A±2.0% (50-400Hz) |
| Voltios DC | 660mV, 6.6V, 66V, 660V, 1000V ±0.5% |
| Voltios CA | 660mV, 6.6V, 66V, 660V, 750V ±01.5% (50-500Hz) |
| Resistencia | 660Ω, 6.6kΩ, 66kΩ, 660kΩ, 6.6MΩ, 66MΩ ±1.0% |
| Capacitancia | 6.6nF, 66nF, 660nF, 6.6μF, 66μF, 660μF, 6.6mF ±3.0% |
