ARES-10A LINE ARRA ACT. 3VIAS2X10″ LF (CELES-NEO)6X4″ MF (CELES-NEO)3X1.4″ HF (CELES-NEO) GERMAN DSP POW. PEAK LF1400W MF600W HF360W SPL42dB (WATERP) «L&N-AUDIO»
ESPECIFICACIONES:
Type： Active 3-way double 10 inch line array with DSP
Sensitivity： 106 dB
SPL： 142dB PEAK
Frequency range： [+/-3 dB] 50 Hz – 20KHz
Dispersion angle, averaged: [H x V] 90° x 8°, single unit
Power: LF 2 x 10” neo 1400W PEAK
MF 6 x 4” neo 600W PEAK
HF 3 x 1.4” neo 360W PEAK
Input sensitivity: Nominal 0 dBu
Signal input： 1 x XLR (Audio Input)
Signal output： 1 x XLR (Audio Link Out)
DSP interface： Rj45 input (EtherCon) for control using Pronet software
Amplier Technical Specications
Distoration： <0.05%
Amplifier type： Class-D
Output power： HF Amp 500W, MF Amp 900W，LF Amp 1200W
Operating voltage: 220-240v 50/60Hz
Power connector: Powercon® input Powercon® Link
LN-RAY212A Dimensions:
Dimensions(W x H x D) 759 x 325x 450 mm
Weight: 34 kg
