TAURUS-124A LINE ARRAY ACTIVO 4 VIAS 2X12″ LF(CELESTION- NEODIMIO) + 2X10″ MLF ( NEODIMIO) + 4X6.5 HF (NEODIMIO) + 2X3″ HF (CELESTION-NEODIMIO) C/GERMAN DSP POWER PEAK: LF:2000W/MLF:2000W/MF:1200W/HF:320W SPL: 146dB (WATERPROOF) «L&N-AUDIO»

TAURUS-124A LINE ARRAY ACTIVO 4 VIAS 2X12″ LF(CELESTION- NEODIMIO) + 2X10″ MLF ( NEODIMIO) + 4X6.5 HF (NEODIMIO) + 2X3″ HF (CELESTION-NEODIMIO) C/GERMAN DSP POWER PEAK: LF:2000W/MLF:2000W/MF:1200W/HF:320W SPL: 146dB (WATERPROOF) «L&N-AUDIO»

ESPECIFICACIONES:

ype： Active 4-way double 12 inch line array with DSP
Sensitivity： 110 dB
SPL： 146dB PEAK
Frequency range： [+/-3 dB] 48 Hz – 20KHz
Dispersion angle, averaged: [H x V] 120° x 7°, single unit
Power: LF 2 x 12” neo 2000W PEAK
MLF 2 x 10” neo 2000W PEAK
MF 4 x 6.5”neo 1200W PEAK
HF 2 x 3 ” neo 320W PEAK
Input sensitivity: Nominal 0 dBu
Signal input： 1 x XLR (Audio Input)
Signal output： 1 x XLR (Audio Link Out)
DSP interface： Rj45 input (EtherCon) for control using Pronet software

Amplier Technical Specifications

Distoration： <0.05%
Amplifier type： Class-D
Output power： HF Amp 600W,
MF Amp1200 W，
MLF Amp2300 W LF Amp2300 W
Operating voltage: 220-240v 50/60Hz
Power connector: Powercon® Input Powercon® Link

LN-RAY212A Dimensions:

Dimensions(W x H x D) 1248 x 367x 620 mm
Weight: 79kg
